Fluke FLUKE-T130 (4016961) Two-pole Voltage and Continuity Tester

Fluke FLUKE-T130 (4016961) Two-pole Voltage and Continuity Tester

The Fluke T130 Voltage and Continuity Tester with large, easy-to-use buttons, a bright backlit LED indicator and LCD display, display hold, and clear audible and vibrating voltage indicators designed for any work situation.

Features:

• Dual insulated cable tested to 3x the required bend angle provides increased reliability and durability.
• Switchable load: avoid display of ghost voltages allowing you to draw more current from the circuit under test and avoid trip residual-current devices (RCDs)
• Backlit graduated scale and backlit indicators
• Built in electric torch for use in dark areas.
• Audio on/off for testing in quiet areas.
• Improved probe docking for secure storage.
• Phase rotation indicator for 3-phase systems.
• Display hold freezes reading on display until your can view it comfortably.
• Single-pole phase test offers fast identification of live conductors.
• Push-on probe tips, probe tip protector and storage accessory.
• Tip protector serves as an extra hand when opening UK electrical safety outlets.
• Low battery indicator.

Specifications:

• Voltage AC/DC: 6V - 690V
• Continuity: 0 - 400 kΩ
• Frequency: 0 / 40 - 400 Hz
• Phase rotation: 100 V - 690 V
• Resistance measurement: Up to 1999 Ω
• Response Time (LED indicator): < 0.5s
• 200 kΩ input impedance:
• Current draw 3,5 mA @ 690 V
• Current draw 1,15 mA @ 230 V
• 7k Ω input impedance (with load buttons pressed): Current draw 30 mA @ 230 V
• Safety rating:
• CAT II 690V
• CAT III 600V
• IP rating: IP64
• Power requirement: 2 x AAA batteries
• Dimensions (L x W x H): 260mm x 70mm x 38mm
• Weight 0.28kg

Warranty:

• Two Years Warranty Covered By Fluke
