Weldclass WF-06169 Force 135ST TIG/STICK Welding Kit

Weldclass WF-06169 Force 135ST TIG/STICK Welding Kit

The 135ST is an incredibly compact Stick/MMA and DC Lift-Arc TIG welder with grunt, performance, and features that rivals much larger machines. Weighing only 2.3kg and fitted with a 10A 240V plug, it's super portable and versatile. Features include: 140 amps @ 20% output, 3m earth and work leads, shoulder strap and FREE welding gloves, adjustable hot start, adjustable arc force and optional VRD. Maximum electrode size capacity of 3.2mm.

Includes:

• 1 x Earth Lead 3m
• 1 x Stick Lead 3m
• 1 x Shoulder Strap
• 1 x Welding Gloves

Features:

• 140A @ 20% output
• Adjustable Hot Start & Arc Force
• Generator Compatible - min 7kva, ideal 8kva
• Weld with up to 3.2mm electrodes
• LCD Digital Meter
• High OCV for smooth and reliable arc

Specifications:

• Voltage: 10A 240V Plug
•  Functions:
  • Stick (MMA)
  • TIG (Lift)
• Output / Duty Cycle (40c):
  • 140A @ 20%
  • 90A @ 60%
• Standard: AS 60974.2
• Electrode Size Capacity: ≤ 3.2mm
• OCV: 77V (VRD on 13.5V)
• Dimensions (L x W x H): 250mm x 95mm x H140mm
• Weight: 2.3kg

Warranty:

• 6 Month Standard Warranty
• 7 Year Warranty When Registered With Weldclass
