Topcon 1021200-17TS Red Beam Rotary Laser Level Kit with Tripod and Surveyor Staff

Designed for a wide variety of applications, the new RL-H5 series are the next generation of rotating lasers from Australia’s Number 1 rotating laser brand Topcon.

The new RL-H5A is the replacement for Topcon's market leading RL-H4C. It can be used for horizontal and sloping laser applications. Slopes up to ±5% can be used in either the X or Y axis.

Grading, excavating and general construction projects are all perfect applications for the RL-H5A. With the added “Slope Matching” feature, check grade on all your flat and slope work. The 600 rpm rotation speed makes the RL-H5A a great match with any machine mounted laser sensor.

The RL-H5A's popularity lies in its ease of use. With electronic self-levelling, you press the power button and begin levelling work in seconds. If the RL-H5A gets disturbed on the job, it relevels itself automatically. The self-levelling motors are accurate to ±10 arc seconds.

The RL-H5A excels in long range operation. Need to shoot elevations up to 400m from your laser? No problem! This instrument has the power and range to cover a 800m (diameter) jobsite.With efficient power usage, the RL-H5A has a long battery life. The unit also gives you the option of two forms of power, 100 hours of continuous usage with D cell (4 x) batteries (included), or 60 hours with the optional rechargeable (Ni-MH) battery pack.

The RL-H5A is “jobsite tough” and with its IP66 rating, the unit can withstand dust, a sudden shower and even torrential rainfall. Topcon stands behind this reliable and accurate laser with a 5 year guarantee which is the best factory warranty in the industry.

Includes:

• Topcon RL-H5A Rotating Laser Level
• Topcon LS-110D Receiver(Millimetre)
• Topcon Receiver Clamp
• 4 x D-Cell Alkaline Batteries
• Carry Case
• Operator Manual
• Australian Calibration Certificate

Specifications:

• Accuracy: H: ±10 arc seconds
• Self-Levelling Range: Horizontal ±5°
• Working Area: 800m
• Rotation Speed: 600 rpm
• Dust/Water Rating: IP66
• Operating Time: Alkaline (100 hours) ; Ni-MH (60 hours)
• Operating Temperature: -20°C to 50°C

This CPI CSE5M (214263) 5m Aluminium Extendable Measuring Surveyors 'E' Face Staff has easy-to-read graduations. It's also a dual-purpose tool since it has a special measuring ruler scale on the backside which will permit users to read height at eye level. To use the measuring ruler on the back, just extend the rod up until it hits the desired length (underneath an overhang or bridge for example), then read the measurement at the smallest unextended section which is at eye-level. This will give you the distance from tip-to-tip of the rod.

Features:

• 5 telescopic sections
• 5m max read height
• “E” block scale and mm calibrated sides
• Locking buttons
• Clear and durable prints
• Made with heavy duty and tough aluminum making the staff robust tool
• Heavy duty carry bag

Specifications:

• Length: 5m
• 0.8 mm internal aluminum thickness
• Material: Aluminium

The CPI Heavy Duty Dome Head Tripod is ideal for levels, lasers and construction theodolites. Provided with a Triangular head and 5/8’’ Fixing Screw with a hook for Plumb Bob. The Heavy Duty casting provides high quality wear and durability to suit all terrains.High quality Heavy duty durable hinge, clamp, and show casing, Electrostatically powder painted castings for a long-lasting finish. The CPI Heavy Duty Dome Head Tripod also comes with a heavy-duty poly-webbing shoulder strap to make sure you can take it anywhere you need to go. It also features pointed feet which can withstand the most toughest terrains no matter where you are.

Features:

• Dome Head
• Telescopic Extension
• Quick Release Plate
• Multi Function Hook
• Pointed Feet
• Leg Clips
• Lightweight Aluminium Alloy Body

Specifications:

• Height:
  • Extended: 1700mm
  • Collapsed: 1040mm
• Dome Head Size: 160mm
• Weight: 4.2kg

Warranty:

• 12 Month Warranty covered by CPI Australia
