Makinex GEN-10P-AU-240-20 8kW 10kVA 3-Phase Petrol Generator

The 10kVA 230/415V generator is ideal for professionals in the construction and flooring industries. Suitable for use in rental yards, construction sites, and rural areas, it provides a convenient, compact, portable way to power 230V single phase and 415V three phase equipment.

Weighing a little more than 100 kilos you can have the 10kVA generator off your truck and in position where it is needed, with no fuss at all. Designed with advanced magnetic flux alternator technology the generator produces power from a much smaller package than competitive generators with the same rating.

This light, compact 10kVA petrol generator packs a big punch for its small size. It simultaneously powers two single phase tools up to 15A and one three-phase 11A/415V machine. And with power outlets included as standard, there is no messing with voltage switches, just plug in and go.

Features:

• All Makinex products are designed and built to endure the rigors of the rental market
• Advanced alternator tech saves 15% fuel versus similar generators using the same engine
• Designed for maximum convenience and ease for concrete, masonry and flooring pros
• Light, portable 10kVA 230V/415V 3-phase generator
• 3-phase and single phase outlets on same machine
• Power multiple medium-duty tools at the same time
• Fold down handle makes it easy to move and store
• Large wheels for maneuverability around job site

Specifications:

• Engine Model: Honda GX390
• Max Output: 10kW / 10kVA
• Rated Output: 6.4kW
• Voltage: 230V Single Phase; 415V Three Phase
• Frequency: 50Hz
• Max Amps:
  • Single Phase: 15A @ 230V
  • Three Phase: 11A @ 415V
• Displacement: 389cc
• Rated Power Factor: 0.8
• Engine Type: Single cylinder air cooled petrol
• Start: Pull Start
• Fuel Tank Capacity: 6.5L
• Fuel Economy: 2.4 L/H @ 50% Load
• Sockets Provided:
  • 2 x 15A Single Phase
  • 1 x 20A 3 Phase sockets with RCBO protection
• Noise Level (7m):
  • No Load: 72dB
  • 50% Load: 76dB
  • 100% Load: 78dB
• Dimensions (L x W x H): 598mm x 609mm x 1162mm
• Weight (Dry): 100kg
