Macc MB-411CSO-3 400mm x 200mm 2HP Three Phase Swivel Head Band Saw

Macc MB-411CSO-3 400mm x 200mm 2HP Three Phase Swivel Head Band Saw

The Macc 400mm x 200mm 2HP Three Phase Swivel Head Band Saw incorporates a recirculating coolant system, and a swivel head that enable 0° to 60° mitre cuts. It has a duel direction heavy duty vice, and an adjustable material stop for repetitive production.

Features:

• Swivel head enables 0° to 60° mitre cuts
• Dual mode operation
• Trigger switch with manual downfeed for small quick cuts
• Control panel with fully adjustable hydraulic down feed & automatic shut-off at end of cut, for cutting larger material
• Dual direction heavy duty vice
• Incorporated recirculating coolant system
• Adjustable material stop for repetitive production
• Comes complete with stand & blade
• Italian made quality

Specifications:

• Motor: 2HP
• Voltage: 415V
• Phase: Three
• Blade Speed: 2 Speed 38 / 77mpm
• Blade Size: 27mm x 0.9mm x 3200mm
• Cutting Angle 90°
• Cylinder: 300mm
• Box: 280mm x 280mm
• Rectangle: 400mm x 200mm
• Cutting Angle 45° Right
• Cylinder: 240mm
• Box: 220mm x 220mm
• Rectangle: 240mm x 130mm
• Cutting Angle 60° Right
• Cylinder: 140mm
• Box: 140mm x 140mm
• Rectangle: 140mm x 140mm
• Cutting Angle 45° Left
• Cylinder: 180mm
• Box: 160mm x 160mm
• Rectangle: 180mm x 110mm
• Weight: 530kg
