Leica Lino P5-1 (LG864427) 5 Point Red Beam Laser Level

Leica Lino P5-1 (LG864427) 5 Point Red Beam Laser Level

The Leica Lino P5-1 is a self-levelling multifunctional point laser. It is a reliable precision laser for any kind of tasks like levelling, plumbing, transfering and setting out right angles. It supports you on job side with vertical and horizontal five points (four points and one point in front of the device) which are arranged precisely in 90° to each other.

The high-precision optics of the Leica Lino P5 ensure outstanding laser line visibility up to 25 meters, depending on lighting conditions. Its exceptionally long horizontal and vertical laser lines are projected to floors, walls and ceilings at more than 180 degrees.

Smart adapters allow for quick and precise positioning. You can set up rotatable adapters over edges and profiles, or easily attach them to iron pipes, tracks and bars.

Features:

• Impact-absorbing rubber pads to withstand bumps and drops
• Triple power concept for continuous operation without rest, no downtime
• Compact ergonomic design with anti-slip surface to avoid mistakes and with a ingoing surface for better grip and control of the unit
• Self levelling pendulum with pendulum lock
• Intuitive one button operation for a quick setup
• Extended vertical laser fan angle
• Tough aluminium window frame protects the precision optics against bumps and shocks
• Huge vertical laser fan angle provides the best visibiity on bottom and over the zenith
• Automatic pulse mode for receiver
• Dust and spray water protected to IP54 standards. This makes it a rugged instrument suitable for all your jobs.

Specifications:

• Range: Up to 30m depending on lighting conditions
• Leveling Accuracy: ±0.0079"/m (±0.2mm/m)
• Self-Leveling Range: ±4°
• Self-Leveling Time: <3 seconds
• Laser Type: 635 nm/class 2
• Operating Temperature: -10 to 50°C
• Storage Temperature: -25 to 70°C
• Battery Type: Li-Ion Battery Pack - or - 3 x 1.5V AA
• Operating Time with Li-Ion Battery Pack: Up to 100h depending on laser mode
• Operating Time with Alkaline Batteries: Up to 37h depending on laser mode
• Protection Class: IP54
• Dimensions: 110mm x 60mm x 100mm
• Weight (with Li-Ion/Alkaline Battery): 0.53kg/0.5kg
