Kemppi MinarcMig Auto 190 (61008190AU) 190A Portable MIG/MAG Welding Machine

Kemppi MinarcMig Auto 190 (61008190AU) 190A Portable MIG/MAG Welding Machine

A 14.2 kg, portable MIG/MAG welding machine providing 190 A with a 35% duty cycle from a 16 A, single-phase mains supply. Manual and synergic welding options available. Compatible with a wide range of materials, including steel (Fe), stainless steel (Ss), aluminum (Al), and CuSi brazing filler wires. A 3-meter welding torch with an ergonomic gun handle, cable set, and carrying strap included.

Features:

• Precise weld quality and arc ignition with adaptive regulation
• Just select material type and the plate thickness and weld in auto mode
• 220A / 190A MIG/MAG welding power from a 16A supply
• Automatic or manual model power regulation
• Compatible with Fe, Fe FCW, Ss, Al, CuSi filler wires, 1 kg, and 5 kg wire spools
• A large graphical backlit display guides you in low-light conditions
• Designed for use with long power extension cables (up to 100m)
• A 3-meter welding torch with an ergonomic gun handle, cable set, and carrying strap included. 
• Suitable for mains network or generator use

Specifications:

• Connection voltage 1~ 50/60 Hz: 230 V ±15%
• Welding Range: 20 A / 15 V...190 A / 26 V
• Output:
  • 35% ED: 190A
  • 60% ED: 140A
  • 100% ED: 100A
• Open circuit voltage: 70-75V
• Wire Feed Mechanism: 2-roll, single-motor
• Wire Spool Max Weight: 5kg
• Wire Spool Max Diameter: 200mm
• Mains fuse: 16A
• Shielding gas pressure (max): 0.5MPa
• Degree of protection: IP23
• Standards: IEC 60974-1, -5, -10, IEC 61000-3-12
• EMC Class: A
• Operating Temperature Range: -20ºC - 40ºC
• Storage Temperature Range: -40ºC - 60ºC
• Dimensions (L x W x H): 450mm x 227mm x 368mm
• Weight: 14.2kg

Warranty:

• 3 Year Warranty Covered by Kemppi
