Kemppi Master M 205 GM AU (P519GXe3AU) 200A Pulse Compact Gas Cooled MIG/MAG 240V Combo Kit

Kemppi Master M 205 GM AU (P519GXe3AU) 200A Pulse Compact Gas Cooled MIG/MAG 240V Combo Kit

A portable multiprocess welder for Australian markets. The power source provides 200 A with a 40% duty cycle. Manual, synergic, and pulse MIG welding options available, along with stick and DC TIG welding options. Intelligent welding parameter setting with Weld Assist. Includes 20 factory-installed welding programs for 1-MIG and 17 factory-installed welding programs for pulse MIG. Welding programs include Fe, Ss, Al, CuSi, and CuAl materials. Suitable for generator use.

Features:

• Versatile process selection with premium MIG/MAG, DC TIG, and stick welding options
• Master M 205 includes a pulse MIG welding option with a 1-phase power supply
• Lightweight and portable welders that are easy to carry anywhere
• Ideal for tight workspaces • Master M 323: 28 factory-installed MIG/MAG welding programs
• Master M 205: 17 pulse MIG welding programs and 20 1-MIG welding programs as a standard
• Root pass welding, thin sheet welding, and gap bridging with MAX Cool arc welding process as a standard in Master M 323
• Master M 323 includes the Gas Guard feature and gas regulation valve
• Self-charging LED work lights for better worksite safety
• Designed to be lifted with a crane
• Weld Assist feature for fast parameter setting
• 6 memory channels
• 40 % duty cycle
• Compatible with generator
• Multivoltage as a standard feature
• Alternative transport cart options

Specifications:

• Connection voltage 1~ 50/60 Hz: 220 – 240 V ±10 %; 110 – 130 V ±10 %
• Fuse: 16/16 A
• Output:
  • 40% ED: 200 A (175 A MMA); 120 A (100 A MMA) (30% ED)
  • 60% ED: 170 A (150 A MMA); 95 A (80 A MMA)
  • 100% ED: 140 A (120 A MMA); 75 A (65 A MMA)
• Wire Feed Mechanism: 2-roll, single-motor
• Wire Feed Speed: 0.5 – 25 m/min
• Rated power at max. current: 6kVA
• Gun Connection: Euro
• Wire Spool Max Weight: 5kg
• Wire Spool Max Diameter: 200mm
• Filler Wires:
  • Ss: 0.8mm – 1.0 mm
  • Al: 0.8mm – 1.2 mm
  • Fe: 0.8mm - 1.0mm
• Welding current and voltage range:
  • MIG: 15 A/10 V...200 A/28 V; 15 A/10 V...120 A/21 V
  • TIG: 15 A/1 V...200 A/28 V; 15 A/1 V...120 A/21 V
  • MMA: 15 A/10 V...175 A/31 V; 15 A/10 V...100 A/24 V
• Degree of protection: IP23S
• Standards: IEC 60974-1, -10
• EMC class: AOperating temperature range: -20ºC - +40°C
• Storage temperature range: -40ºC - +60 °C
• Dimensions (L x W x H): 520mm x 250mm x 379 mm
• Weight: 16.2 kg

Warranty:

• 3 Years Warranty Covered by Kemppi
