ITM WP270SH-1 220mm x 220mm 1.5HP Single Phase Swivel Head Band Saw

ITM WP270SH-1 220mm x 220mm 1.5HP Single Phase Swivel Head Band Saw

Features:

• Swivel head enables 0° to 60° mitre cuts
• Dual mode operation:
  • Trigger switch with manual downfeed for small quick cuts
  • Control panel with fully adjustable hydraulic down feed
• Automatic shut-off at end of cut, for cutting larger material
• Incorporated recirculating coolant system
• Brass chip brush to help prevent blade breakage
• Adjustable material stop for repetitive production

Specifications:

• Motor: 1.5HP Single Phase
• Blade Speed: Single Speed 72mpm
• Blade Size: 27mm x 0.9mm x 2460mm
• Bed Height: 885mm
• Cutting Angle 90°:
• Round: 227mm
• Square: 220mm x 220mm
• Rectangle: 260 x 110mm
• Cutting Angle 45° Right:
• Round: 150mm
• Square: 145mm x 145mm
• Rectangle: 200 x 145mm
• Cutting Angle 60° Right:
• Round: 90mm
• Square: 85mm x 85mm
• Weight: 216kg

Warranty:

• 1 Year Standard Warranty Covered By ITM
