Fluke FLK-II910 (5233904) Precision Acoustic Imager

Fluke FLK-II910 (5233904) Precision Acoustic Imager

Features:

• Detect partial discharge early allowing for proper scheduling of maintenance. This increases uptime Quickly and easily scan areas to find potential problems
• Detect and analyse partial discharge from a safe distance
• Partial discharge detection: ii910 allows to detect Corona and Partial Discharge (PD), even when there is no direct line of sight. The high sensitivity of ii910 allows you to detect PD at earlier stages, enabling condition-base maintenance and planning service of equipment (vs preventive replacing/servicing/cleaning)
• SoundSightTM: With SoundSightTM technology the ii910 translates the sounds that it hears into a visual representation so that you can easily scan and quickly locate problem areas.
• Ease of use: ii910 allows untrained users to detect, locate, and assess the severity of Partial Discharge, Corona Discharge or Gas/Vacuum leaks, easier, faster, and more effectively than existing Ultrasonic Tools, by using visual images to better pinpoint and report PD, Corona or Gas leak.
• PDQ ModeTM: ii910 provides a relative severity of a discharge, that provides information to the user on whether action may or may not be needed after PD has been detected.
• LeakQTM: Estimate the size and cost of a leak Including a new distance-estimation feature and the 1-10 LeakQTM severity index. Images can be uploaded to the online web to generate leak reports including leak size and cost estimation.

Specifications:

• Sensors:

  • Frequency band: 2 kHz to 52 kHz
  • Detection range: 0.5 to > 120 meters (1.6 to > 393 feet)*
  • Field of View: 63 ° ± 5 °
  • Normal Frame Rate 25 FPS
• Built-in digital camera (visible light)
  • Field of View (FOV): 63 ° ± 5 °
  • Focus: Fixed lens
• Display: 7" LCD with backlight, under-sunlight readable
  • Resolution: 1280 x 800 (1,024,000 pixels)
  • Touchscreen: Capacitive
  • Acoustic Image: Yes, SoundMap™ image
• Image storage:
  • Storage capacity: Internal memory with the capacity for 999 picture files or 20 video files
  • Image format: Blended visual and SoundMap™.JPG or .PNG
  • Video format: Blended visual and SoundMap™.MP4
  • Video length: 5 minutes maximum
  • Digital export: USB-C for data transfer
• Acoustic Measurements
  • Measurement range:
    • 12.1 dB SPL to 114.6 dB SPL ±1 dB SPL 2 kHz
    • 4.4 dB SPL to 101.2 dB SPL ±2 dB SPL 19 kHz
    • 12.8 dB SPL to 119.2 dB SPL ±1 dB SPL 35 kHz
    • 19.8 dB SPL to 116.1 dB SPL ±3 dB SPL 52 kHz
    • 41.4 dB SPL to 129.0 dB SPL ±1 dB SPL 80 kHz
    • 54.4 dB SPL to 135.5 dB SPL ±1 dB SPL 100 kHz
  • Auto max/min dB gain: Auto or manual, user selectable
  • Frequency band selection: User selectable through user-made presets or manual entry
• Software:
  • Ease of use: Intuitive user interface
  • Trend graphs: Frequency and dB scale
  • Spot markers: dB level reading at center point of the image
• Battery:
  • Batteries: rechargeable
  • Battery life 6 hours (product includes spare battery)
  • Battery charging time 3 hours
  • Battery charging system External dual-bay charger, EDBC 290
• General Specifications
  • Standard palettes 3: Grayscale, Ironbow, Blue-Red
  • Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F)
  • Storage Temperature: -20 °C to 70 °C (-4 °F to 158 °F) Without batteries
  • Relative humidity: 10 % to 95 % non-condensing
• Main unit rating: IP40 protection against particles 1mm or greater and dripping water
• Sensor head rating: IP51
• Self-diagnostic notification: Array-health test to identify when microphone array needs attention
• Supported languages: Dutch, English, Finish, French, German, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese
• RoHS compliant: Yes
• Safety:
  • General Safety IEC 61010-1
  • Electromagnetic Compatibility (EMC) International IEC 61326-1: Portable Electromagnetic Environment IEC 61326-2-2
  • CISPR 11: Group 1, Class A
• Dimensions (L x W x H) 186mm x 322mm x 68mm
• Weight: 1.7kg

Warranty:

• 2 years warranty covered by Fluke
