Fluke 6200-2 AU (4324482) 6200-2 Portable Appliance Tester

Fluke 6200-2 AU (4324482) 6200-2 Portable Appliance Tester

The Fluke 6200-2 PAT tester is a low weight, small size, one-touch solution with redesigned auto-test capabilities to help you increase the number of portable appliance tests completed each day. The 6200-2 is designed to enable you to work faster without compromising safety – yours or your customer’s.

Features:

• Dedicated key for each test for ‘one-touch’ testing
• Pre-set pass/fail levels to save time
• Large backlit display for easy reading
• Single mains socket for appliance connection
• Separate IEC socket for easy mains/extension lead testing
• Detachable test leads for quick field replacement
• Integral carrying handle
• USB port for data transfer

Specifications:

• Power-on test
• Display range: 90 V to 264 V
• Accuracy at 50 Hz: ±(2% + 3 counts)
• Resolution: 1 V
• Input impedance: > 1 MΩ // 2.2 nF
• Maximum input mains voltage: 264 V
• Earth bond test (R pe)
• Display Range: 0 to 19.99 Ω
• Accuracy (after bond test zeroing): ±(2.5% + 4 counts)
• Resolution: 0.01 Ω
• Test current:
• 200 mA AC -0% +40% into 1.99 Ω
• 25 A AC ±20% into 25 mΩ at 230 V
• Open circuit voltage: > 4 V AC, < 24 V AC
• Bond test zeroing: Can subtract up to 1.99 Ω
• Insulation test (R iso):
• Display range: 0 to 299 MΩ
• Accuracy: ±(5% + 2 counts) from 0.1 to 300 MΩ
• Resolution: 0.01 MΩ (0 to 19.99 MΩ), 0.1 MΩ (20 to 199.9 MΩ), 1 MΩ (200 to 299 MΩ)
• Test voltage: 500 V DC -0% + 10% at 500 kΩ load
• Test current: > 1 mA at 500 kΩ load, < 15 mA at 0 Ω
• Auto discharge time: < 0.5 s for 1 μF
• Max. capacitive load: Operational up to 1 μF
• Touch current test:
• Display range: 0 to 1.99 mA AC
• Accuracy ±(4% + 2 counts)
• Resolution:0.01 mA
• Internal resistance (via probe): 2 kΩ
• Measuring method Probe (The appliance under test is energized at mains potential)
• Substitute leakage current test:
• Display range: 0 to 19.99 mA AC
• Accuracy: ±(2.5% + 3 counts)
• Resolution: 0.01 mA
• Test Voltage: 100 V AC ±20%
• Load/leakage test: load current:
• Display range: 0 A to 13 A
• Accuracy: ±(4% + 2 counts)
• Resolution: 0.1 A*
• Load/leakage test: load power:
• Display range 230 V Mains: 0.0 VA to 3.2 kVA
• Accuracy: ±(5% + 3 counts)
• Resolution: 1 VA (0 to 999 VA), 0.1 kVA (>1.0 kVA)*
• Load/leakage test: leakage current:
• Display range 0 to 19.99 mA
• Accuracy: ±(4% + 4 counts)
• Resolution: 0.01 mA*
• PELV test:
• Accuracy at 50 Hz: ±(2% + 3 counts)
• Overload protection: 300 V rms
• Warning threshold: 25 V rms
• Operating temperature: 0 to 40 °C
• Relative humidity:
• Non condensing <10 °C
• 95% from 10 to 30 °C
• 75% from 30 to 40 °C
• Safety rating: CAT II, 300 V, pol 2
• Power supply: 230 V +10% -15%, 50 Hz ±2
• Power consumption (tester):
• 13 W typical (idle)
• 60 W max. during 25A Bond test
• Storage Temperature: -10 to 60 °C
• Storage Corrosion: 70 °C @ 95% RH for 5 days max.
• Operating altitude: 0 up to 2000 m
• Sealing: IP-40 (enclosure), IP-20 (connectors)
• EMC: Complies with EN61326-1, portable
• EMI Immunity: 3 V/m
• Dimensions (L x W x H): 200mm x 278mm x 114mm
• Weight 3.13kg

Warranty:

• Two Years Warranty Covered By Fluke
