Fluke FLK-TIX620 (4830517) Infrared Camera

Fluke FLK-TIX620 (4830517) Infrared Camera

Features:

• 640 x 480 resolution infrared camera with advanced focus and a large 5.6 inch high resolution LCD screen
• Features 32x on-camera digital zoom to allow you to get close up shots from a safe distance
• Offers multiple image transfer protocols
• Provides the sharpest ever IR-Fusion® images with an 8 MP visible light camera
• Subject to Export Control

Specifications:

• IFOV (spatial resolution): 0.85 mRad
• Image resolution (pixel): 640 x 480 (307,200 pixels)
• Frame rate (@ max. image resolution): 30 and 9 Hz
• SuperResolution & Dynamic SuperResolutin (resolution enhancement): No
• Subwindowing  modes available - subwindowing options are not available on 9 Hz models: (add on at time of order): Option 1: 384 × 288
• Field of View (FOV) w/standard 30mm lens: 32.7° x 24.0°
• Thermal sensitivity (NETD): < 0.04ᵒ C at 30ᵒ C target temp (40 mK)
• Spectral range: 7.5 µm to 14 µm
• Temp Measurement:
  • Range: -40 °C to 600 °C (-40 °F to 1112 °F)
  • Accuracy: ± 2 K or ± 2 %
  • Correction functions: Emissivity (manual or material table)
  • Transmissivity, ambient temperature, humidity (option)
• Image/video storage: SDHC memory card
• Interfaces for image/data transfer: Supported in camera data ports: Image transfer, SD card, USB 2.0, video output DVI-D (HDMI). GigE vision and RS232
• Laser pointer: Class 2
• Protection class: IP54
• Dimensions (L x W x H): 220mm x 125mm x 155mm
• Weight: 1.5kg
