FLIR DM66 Multifunctional Digital Multimeter with VFD Mode

FLIR DM66 Multifunctional Digital Multimeter with VFD Mode

The DM66 digital multimeter is ideal for automation field service or electronics technicians, providing a comprehensive feature set including low impedance (LoZ) mode, frequency, diode, capacitance, and a Type K thermocouple input for temperature measurement. The multimeter combines rich features, precise measurements, and quality construction into a tool of exceptional value. Easy to use and built to last, the DM66 offers long-term stability for everyday use.

Includes:

• 3x AA Battery

Features:

• Provides rich features for various electrical applications including AC/DC measurement, safe non-contact voltage detection, a flashing backlight, and audible indicator
• Navigate the meter’s on-screen menu system easily, and operate one-handed thanks to the compact design and easy-to-access buttons
• The DM66 is drop-tested, IP40 rated, and has a CAT IV-300V, CAT III-600V safety category rating to ensure safe and accurate operation

Specifications:

• AC/DC Amps:
  • Range: 10.00 A
  • Basic Accuracy: ±1.5% / ±1.0%
• AC/DC LoZ V:
  • Range: 600.0 V
  • Basic Accuracy: ±2.0%
• AC/DC mAmps:
  • Range: 600.0 mA
  • Basic Accuracy: ±1.0% / ±0.7%
• AC/DC microAmps:
  • Range: 6000 µA
  • Basic Accuracy: ±1.5% / ±1.0%
• AC/DC mVolt: Range:
  • 600.0 mV
  • Basic Accuracy: ±1% / ±0.4%
• AC/DC Voltage: Range:
  • 600.0 V
  • Basic Accuracy: ±1.0% / ±0.4%
• Capacitance: Basic Accuracy: 200.0 nF ±1.5% 200.0 µF ±1.5% 10 mF ±4.5% 10.00 mF ±5.0%
• Continuity Check: 30Ω - 480Ω
• Diode Test:
  • Range: 3.000 V
  • Basic Accuracy: ±0.9%
• Frequency Range: 50.00 kHz
• Resistance: Basic Accuracy: 600.0 kΩ ±0.5% 6.00 MΩ ±0.3% 60.00 MΩ ±0.9%
• Thermocouple: –40 to 752.0°F DMM ± (1.0% + 3°F), –40 to 400°C DMM ± (1.0% + 1.5°C)
• True RMS: Yes
• VFD AC Voltage:
  • Range: 600.0 V RMS
  • Basic Accuracy: ±1.0%
