Flextool FT201798-UNIT + FT201801-UNIT + ILFH20 (FDU-P2 + FP212G-6) 5.5HP Petrol Super Drive Unit with 6m General Trash Pump Combo Kit

The Flextool Super Drive Unit FDU-P2 is fitted with a quick action coupling for quick and easy connection of a wide range of flexible shaft submersible pumps and concrete vibrators. It has heavy duty engine protection frames along with crane lifting hook for easy and safe onsite handling. The FDU-P2 model also has dished steel base for easy mobility over concrete reinforcing mesh and spring and rubber mounts for vibration isolation.

Features:

• Fitted with a quick action coupling for quick and easy connection of a wide range of flexible shaft submersible pumps and concrete vibrators fitted with a 3-tooth drive coupling
• Honda 4-stroke engine for hassle free operation and low engine emissions
• Durable heavy duty motor protection frame
• Heavy duty rubber mounts for vibration isolation
• Dished steel base for easy mobility over concrete reinforcing mesh
• Lifting hook for easy and safe onsite handling
• An oil level sensor is fitted to protect the motor from a lack of crankcase oil.

Applications:

• Construction
• Hire industry
• Manufacturing industry

Specifications:

• Max rated power: 5.5HP
• Speed: 3000rpm
• Fuel type: Petrol
• Engine: Honda GX160
• Vibration isolating mounts: Yes
• Lifting hook: Yes
• Operating weight: 32kg

Operated by either a petrol or diesel portable drive unit, the Flextool General Purpose Submersible Pump is a highly efficient submersible unit that is completely self-priming and has an extremely robust design. The flexible drive shaft means it can be used in many situations where close coupled pumps would not be suitable. The heavy-duty and double row oil bearings ensure extended service life, and the flexshaft support springs protect the drive shaft when operating over the sharp edge of excavations, pits, dams and other similar applications. A corrosion-resistant stainless-steel spindle rounds off the pump’s build to set the benchmark for performance and durability. The Flextool General Purpose Submersible Pump is ideal for applications such as excavation pits, construction sites, dams, trenches, pier holes and swimming pools and should be used in combination with the Flextool Lay Flat Hose.

Features:

• Heavy-duty and double row oil bath bearings ensure extended service life
• Oil bath lubrication protects against overheating when not submerged in water (runs dry)
• Corrosion resistant stainless-steel spindle for durability
• Seven oil seals provide superior protection to bearings and reduces maintenance intervals
• Hardened steel wear plates protect components from wear and extends service life of pump when used in abrasive pumping applications
• Heavy-duty choke resistant impeller is designed to resist choking and overload when foreign objects enter pump body
• 28 mm solids pumping capacity for rapid pumping of solids in even the toughest of conditions
• Quick-action camlock hose fitting for tool-free and quick connection
• Lifting eyelets for connection of rope or chain when lowering the pump into deep pits to protect flexshaft from scratching
• 3 x 1 metre long flexshaft support springs protect the drive shaft when operating over the sharp edge of excavations, pits, dams, etc
• Additional 8 metre support rope for use when the pump head is unable to rest on a surface

Applications:

• Excavation pits
• Constrution sites
• Pier holes
• Dams
• Swimming ppols
• Trenches

Specifications:

• Flexshaft length: 6m
• Shaft inner core diameter: 13mm
• Shaft chasing diameter: 32mm
• Discharger diameter: 50mm
• Max discharge head: 26m
• Max discharge: 63,000L/h
• Solids capacity: 28mm
• Operating weight: 26.5kg

The Industek 20m Lay Flat Hose is lightweight and flexible. With it's strong textile reinforcement and UV resistant material, the hose can be left in sunlight without worry of damage, ensuring a long service life. The flexible hose has the ability to be joined and expand it's length, giving versatility for its user. It's heavy duty locking mechanism creates a tight seal, and be easily opened by the locking arms. Excellent durability is achieved through the stainless steel impeller, for increased abrasion resistance and a longer life.

Features:

• UV Resistant
• Anti-Stretch
• Lightweight & Flexible
• Strong Textile Reinforcement
• Joinable Heavy Duty Lay Flat Hose
• Stainless Steel Impeller for Improved Abrasion Resistance
• Includes Attached Heavy Duty Cam Lock Fittings
• Fitted with an Adaptor for Camlock Quick Action Hose Fittings

Specifications:

• Pressure: 43PSI
• Length: 20m
• Hose Diameter: 50mm
