Eslon 502141 (ESZ3NGC) 3M Non-Conductv Pocket Tape

Eslon 502141 (ESZ3NGC) 3M Non-Conductv Pocket Tape

Features:

• High accuracy measure perfected from all angles
• Expansion-free fiberglass tape with special plastic coating
• Latest design with uprightness, horizontality and automatic winding
• Large figures for easy reading, and adoption of continuous figures on entire length
• The tape is made from fiberglass reinforced plastic with urethane coating
• The case is realized in a compact size with light and rigid ABS resin and does not use any metal on surface
• The case can stand upright and has excellent workability thanks to the auto rewind device
• Excellent oil resistance, waterproofing and solvent resistance
• Excellent accuracy scale when compared to that of a steel tape

Speicfications:

• Tape length: 3M
• Width 19mm
• Thickness 0.3mm
• Scale accuracy: 3mtr +/- 0.9mm (JIS Class 2)
• Elongation 2.5% (breaking extension) – tensile strength 100kgf
• Insulation performance:
  • Dry 20kV or over 10cm
  • Wet 20Kv or over 10cm
