EFO PR3 CAT IV Phase Rotation Meter

EFO PR3 CAT IV Phase Rotation Meter

The EFO Phase Rotation Meters have been designed to offer the highest Safety Rating CATIV 600V. The PR3 Phase Rotation Meters are designed for Use with Utility workers, ASP Service providers, Industrial, Commercial and General Electricians.

Features:

• Two functions in one unit: open phase and phase rotation and sequence
• Lamps let you determine at-a-glance if phase is open
• Fused Test Leads for Safety
• Probes and alligator clips included
• Large size alligator clips for easy clipping onto switch-boards terminals
• Instruction manual and Soft Pouch Included
• CAT IV 600V Safety Rating
• Checks a wide range of 3-phase power sources

Specifications:

• Voltage: AC 200V-600V AC
• Frequency response: 50 / 60Hz
• Operating temperature & humidity:
• @ 80% max relative humidity: 0°C ~ 40°C
• @ 90% max relative humidity: 10°C ~ 50°C
• Dimensions (L x W x H): 134mm x 85mm x 45mm
• Weight: 0.53kg
• Safety standard: EN 61010-1
