Cigweld W1008180 180A DC Stick & Lift TIG Multi Process Inverter Welder

Cigweld W1008180 180A DC Stick & Lift TIG Multi Process Inverter Welder

The WeldSkill 180 is a single phase welding inverter with a user-friendly control panel, practical push button operation for mode selection, clearly visible LED indicators and
sturdy large control knob.

Affordable, compact and light-weight, this unit is a great addition to the shed ensuring the ultimate portability for the Home Handyman, Tradesman, Farmer or Maintenance Worker.

In addition to its appealing design and functional features, the WeldSkill 180 provides the added reassurance of a high quality welding inverter that complies to Australian
Standards. Simply plug it into any standard 15 Amp power point and get welding right away!

Features:

• 240 Volt, 15 Amp Supply Lead & Plug Fitted to Power Source
• Fully compliant to AS 60974.1-2006
• Max. Electrode Size 4.0mm. Suitable for All Electrode Types Except AWS E6010 Cellulose
• Over Temperature Cut Out Protection has been fitted to Power Source
• Hot Start Improves the arc start characteristics of stick electrodes
• Anti Stick helps to prevent the stick electrode from sticking to the work piece
• Arc Force assists when stick welding in a tight corner or joint fit-up
• Current Range for this Power Source is 10A to 180A of DC Welding Output
• DC Lift TIG function provides smooth starting and running characteristics across a broad range of applications
• Rugged case with carry handle and carry strap
• 4m Long Electrode Holder & Work Leads
• Twistlock Electrode Holder allows the electrode  to be locked securely in place

Specifications:

• Cooling: Fan cooled
• Welder type: Stick & Lift TIG Multi Process Inverter Power Source
• Australian standards: AS 60974.1-2006 / IEC 60974-1
• Phases: Single
• Nominal supply voltage: 240V AC ± 10%
• Nominal supply frequency: 50/60Hz
• Welding current range: 10 - 180A
• DC open circuit voltage: 78V
• Fitted supply plug rating: 15Amps
• Effective input current (I1eff ): 15Amps
• Maximum input current (I1max): 33.8Amps
• Minimum single phase generator recommendation: 7.6 kW (9.5 kVA @ 0.8 PF)
• Stick (MMAW) welding output (40ºC, 10 min): 180 Amps @ 20% Duty Cycle
• TIG (GTAW) welding output (40ºC, 10 min): 180 Amps @ 40% Duty Cycle
• Protection class: IP21S
• Dimensions (L x W x H): 340mm x 130mm x 220mm
• Weight (power source only): 5.8kg

Warranty:

• 3 Years Warranty on Power Source with Cigweld Australia
