Cigweld W1005185 Transmig 175i+ 3-In-1 Multi Process Inverter Welder

Cigweld W1005185 Transmig 175i+ 3-In-1 Multi Process Inverter Welder

The CIGWELD TRANSMIG 175i+ is a self contained single phase multi process welding inverter that is capable of performing GMAW/FCAW (MIG), MMAW (Stick) and GTAW (Lift TIG) welding processes. The unit is equipped with an integrated wire feed unit, voltage reduction device (VRD applicable in Stick mode only), digital voltage and amperage meters, and a host of other features in order to fully satisfy the broad operating needs of the modern welding professional.

Includes:

• Transmig 175i+ Inverter power source
• Tweco Professional Fusion 250 MIG Torch, 3m
• COMET Professional Argon Regulator/Flowmeter
• Feed Rolls: 0.6/0.8mm V Groove (fitted), 1.0/1.2mm U Groove, 0.8/0.9mm V Knurled
• Contact Tips: 0.8mm (fitted), 0.6mm, 0.9mm, 1.0mm
• Twist Lock Electrode Holder with 4m Lead
• Work Clamp with 4m Lead
• Shielding Gas Hose Assembly
• Shoulder Strap
• Product Bag
• Operating manual (not pictured)

Features:

• 185A (MIG Mode) 3-in-1 MIG / Stick / Lift TIG Inverter Welder
• Digital Amperage and Voltage Meters
• Highly portable with carry handle, carry strap and under 15kg
• Full multi process capabilities; MIG, Stick and Lift TIG
• Integrated Wire Feed Unit ‰ Spools up to 5kg or 200mm
• Standards compliant VRD
• Fully compliant to AS 60974.1-2006. Enclosure Rated to IP23S - Designed for Indoor & Outdoor use.
• Arc Control (Inductance) for adjusting intensity of the arc
• Adjustable Burnback Control for controlling MIG wire stick out
• Euro MIG Torch Connection
• Accepts Mechafin style 2R feedrolls
• Robust 50mmå_ Dinse twist lock connections

Specifications:

• Voltage: 240V +/- 15%, (15 Amp Plug)
• Processes: MIG (GMAW/FCAW), STICK (MMAW), TIG (GTAW)
• Welding Current Range:
• GMAW/FCAW: 10 - 185A MIG
• MMAW: 10 - 175A STICK
• GTAW: 10 - 175A TIG
• Duty Cycle:
• MIG (GMAW/FCAW): 185A @ 20%, 23.3V (40°, 10mins)
• STICK (MMAW): 175A @ 20%, 27.0V (40°, 10mins)
• TIG (GTAW): 175A @ 25%, 17.0V (40°, 10mins)
• Minimum Single Phase Generator Recommended Generator** 9.5 kVA (at 0.8 Power Factor) 7.8 kW (at 1.0 Power Factor)
• Dimensions (L x W x H): 450mm x 210mm x 410mm
• Weight: 23.0kg

Warranty:

• 3 Year Limited Warranty Covered By Cigweld Australia
