Cigweld BlueVenom XF200P3 (W1400200) Multi Process PULSE MIG /STICK-TIG Welding Inverter With 3 Pulse Transfer Modes

Cigweld BlueVenom XF200P3 (W1400200) Multi Process PULSE MIG /STICK-TIG Welding Inverter With 3 Pulse Transfer Modes

The BlueVENOM XF200P3 PULSE MIG is the machine for the serious welding enthusiast, tradesperson or professional who need to fabricate and weld light structures that require TIG-Like welds on Aluminium, Stainless Steel, Bronze or Steel projects, but need the welding speed and ease-of-use of the MIG Process. Suitable for use at maintenance departments, farm/home workshops, jobsites and marine repair/service centers without compromising on price for excellent results! With the avid welder in mind, CIGWELD have introduced “Opti-Start”, a feature that allows the user to customise their starting arc characteristics through Soft and Hard Start controls.

Includes:

• 1 x Power Source
• 1 x CMGBZ24E3 MIG Gun 3m Euro quick connector set up with an Aluminium Liner, plus a spare Steel liner is supplied for hard wires
• 1 x Work clamp with 3m lead
• 1 x TwistLock Electrode Holder with 3m Lead
• 3 x Feed Rolls: 0.8/0.9mm Gasless, 0.9/1.0mm U-Groove for Soft Wires(Fitted), 0.8/0.9mm Solid Wires
• 1 x 2m Argon Gas Hose and Gas Regulator/Flowmeter
• 1 x Yellow Nylon Inlet Guide for use on Soft Alloy Wires
• 1 x Spring Steel Inlet Guide for Hard Wires

Features:

• 3 x Pulse modes: Single & Double Pulse MIG, STICK Pulse and TIG Pulse
• Welding performance made easy to suit the serious welding enthusiast to the welding pro
• Produce terrific welding results from 230V/240V x 15A upgraded power
• Weld most metals including Mild Steel, Stainless Steel, Aluminium and Bronze
• The XF200P3 comes packed with the right liner, inlet guide and feed rollers for hard (steel and stainless) wires as well
• Pre-installed Synergic Quickset MIG (Single & Double Pulse) programs! Simply choose your material and gas combination (unless you’re using gasless), wire diameter and dial up the plate thickness you’re welding and you’re ready to go
• Intuitive 3.5” full colour display to custom set values to get the most out of your welds

Specifications:

• Power Supply: Single-Phase 230V/240V +/- 10%
• Nominal Supply Frequency: 50/60Hz
• Supply Lead and Plug Supplied: 15 Amp
• Minimum Generator Recommendation: 12kVA (at 0.8 Power Factor_ at Max Amps
• Amperage Range (MIG): 30-200A
• Voltage Range (MIG): 15.5-24V
• MIG (GMAW) Duty Cycle @ 40°C, 10 minutes:
  • 200 Amps @ 15%
  • 100 Amps @ 60%
  • 77 Amps @100%
• STICK (MMAW) Duty Cycle @ 40°C, 10 minutes:
  • 195 Amps @ 10%
  • 80 Amps @ 60%
  • 62 Amps @ 100%
• TIG (GTAW) Duty Cycle @ 40°C, 10 minutes:
  • 200 Amps @ 15%
  • 100 Amps @ 60%
  • 77 Amps @ 100%
• Nominal DC Open Circuit Voltage in MIG Mode: 67V
• Open Circuit Voltage (VRD On) STICK Mode: <35V
• Australian Standard: AS 60974.1:2020
• Protection Class: IP 21S
• Dimensions (L x W x H): 495mm x 220mm x 335mm
• Weight: 13.4kg

Warranty:

• 2 Years Warranty Covered by Cigweld (Machine)
