B.T. Engineering 10501 14″/16″ Petrol Brick Saw

B.T. Engineering 10501 14″/16″ Petrol Brick Saw

• Engineered optimal dust suppression, with our custom-designed 3-way independent water button. On/Off, hands-free or constant flow water modes
• Fitted rubber splash guard reduces water spray and slurry build up
• Customed designed & durable carriage tray with removable mitre guide for precise cuts of any length or shape
• Lightweight detachable base and stand with puncture proof tyres, ensures easy manoeuvrability onsite and convenient transport
• Updated blade guard to fit both 14” & 16” blades. Hinged mechanism for continued user protection, effective water disbursement and easy blade changeover
• 3 cutting options using a fixed position, pull down handle or foot pedal
• Zinc electroplating ensures the BT Brick Saw repels dust and corrosion for many years of operation
• Added mounts for belt driven water circulation pumps
• Plus, a wide range of parts to keep your saw running

Specifications:

• Custom designed Cyclone model
• Engine type 4-stroke, overhead valve, single cylinder
• 3/4 keyed horizontal shaft
• Net power: 4.1kW (5.5HP) at 3600 rpm
• Continuous Rated power: 3.7kW (5.0HP) at 3600 rpm
• 196cc Displacement
• Unleaded fuel
• Fuel tank capacity: 3.1 Litres
• Replacement cyclone filters available. 17210-ZE1-505

• Blade diameter:
  • Minimum: 14″ (355mm)
  • Maximum: 16″ (406mm)
• Blade bore diameter: 25.4mm / 1″
• Depth of cut: 125mm (14″) to 145mm (16″)
• Length of cut: 500mm
• Clearance: up to 200mm

• Carriage Dimensions (L x W): 310mm x 440mm
• Weight: 90kg
• Dimensions (L x W xH): 1200 mm x 680 mm x 800 mm

Warranty:

• 1 Year Warranty Covered By B.T. Engineering
