Bessey BEY23 BEYCEPS One-Handed Lifting Clamp

Bessey BEY23 BEYCEPS One-Handed Lifting Clamp

The BEYCEPS is a powerful, one-handed lifting clamp delivering up to 180 kg of lifting force with a wide, flexible working range for professional and DIY assembly tasks. Its ergonomic, safety-focused design features precise control, tool-free conversion, and protective components that safeguard both the user and delicate workpieces.

Features:

• Lifting force up to 1,800 N / 180 kg / 400 lbs
• For lifting (up to 8 mm per operation of the pump lever), lowering (up to 4 mm per operation of the lowering lever) and aligning workpieces with millimeter precision, gently and safely with just one hand
• Ergonomic and safe handling, as the pump lever made of 2-component plastic is positioned on the top and the two levers for fine lowering and releasing are arranged separately below it
• Closed plastic housing protects the mechanism from dust, dirt and chips and prevents fingers from getting trapped
• Can be converted without tools for clamping tasks
• Protective caps for stand and lifting plate – included in the scope of delivery – prevent damage to sensitive surfaces
• CE labelling

Specifications:

• Lifting Force: Up to 180kg
• Utilisation Area
  • Lifting/Spreading: 5mm-230mm
  • Clamping: 170mm-390mm
• Rail: 22mm x 8mm
• Dimensions (LxHxW): 230mm x 175mm x 45mm
• Weight: 1.93kg

Warranty:

• 12 Month Warranty covered by Bessey
